Molybdenum spraying wire Properties:
1. The weight of single wire is up to 20-25kg without any welded joint, which results in enhancing the efficiency and decreasing the operating costs.
2. Diameter: above 0.1mm,;normal size0.5mm-3.0mm
3. Tolerance: 0.15mm + / -0. 025mm or + 0 / -0. 05mm

4. Tensile strength: >700-900N / mm2

5. Elongation: >20-5%.

Specifications of Pure Molybdenum Wire
thermal spray molybdenum wire:
1.good quality
2.high purity
3.small quantity is available
thermal spray molybdenum  wire :


Spray Molybdenum Wire
Name	Chemical Composition	Size	Tensile Strength	Elongation	Application
Spray Molybdenum Wire	Mo 99.95min W<0.020 Fe<0.005 O<0.003 Al<0.002 C<0.004 Si<0.002 P<0.001 Mg<0.001 N<0.003 Ca<0.002 Ni<0.002	0.2-0.3.0mm	700MPamin	6min	To repair the parts of wearing or tearing.

The diamond" the sign superelevation intensity line cuts the special-purpose molybdenum wire, selects the high quality molybdenum raw material, after special purpose equipment, special craft manufacture. The company cuts the special-purpose molybdenum silk to each line to carry on the tensile strength, the elongation ratio, the luster, BBIEN, the precision, the platoon line altogether six quality examinations separately, strictly controls molybdenum to leave the plant the quality. The molybdenum silk tensile strength super nation standard 30%, has the tensile strength high, the elongation ratio is small, uniform good characteristic.

Specification φ (mm) 0.12 0.13 0.14 0.15 O . 16 0.17 0.18 0.20 GB code Tensile strength ≥ 1500 The correspondence pulls the strength(N) 17.0 19.9 23.1 26.5 30.2 34.1 38.2 47.1 Surpasses GB code 30% to pull the strength (N) 23.5 27.6 30.0 34.5 39.2 44.3 49.6 61.3 Each gram silk is long(m / g) 8.669 7.386 6. 369 5.548 4. 876 4. 319 3.853 3.121

Application for Mo wire:
It can be sed for making Mo powder and other semiconductor industry usage;Electronic pulse and medical equipment, cutting equipment and electrode application.

Packing:
1kg/reel,500g/roll:50/rolls export carton：G.W-27.5kg  Size of Carton:36*26*18cm
10kg/bound
1kg/roll: 30rolls/export carton: G.W-31.5kg     Size of Carton:36*26*18cm
MOQ: 10kg
OEM can be discussed,we will use our own label if customers have no other requirement.

Supply ability:
We are specialized in kinds of soldering products
Purity cobalt wire:100kg  per month
Other purity wire or metal:Above 30 ton per month
Solder paste:10-50 ton per month
Other solder:can meet customer's demand
Certificate:
Newest SGS test;ISO9001:2008;RoHS,REACH etc
