BBIEN Halogen Lead free liquid flux for wave soldering welding

SHENZHEN BBIEN TECHNOLOGY'S liquid flux has the following feature:
RoHS-Compliant.
Wave Solder Fluxes that deliver best in class soldering performance and electrical reliability, including options that improve worker safety and are better for the environment.
BBIEN lead free solder flux
·                 VOC-free
·                 Excellent soldering performance
·                 Rosin free formulation results in excellent cosmetics and pin testability
·                 Bellcore RoHS compliant

Cleaning:
BBIEN's lead free fluxis a no-clean chemistry. The residues do not need to be removed for typical applications.
The basic physical characteristics

Project	Test results
Appearance	Colorless, clear fluid
Smell	Alcohol taste
Physical stability	By：5±2 ºC No layered or crystallization precipitation，45±2 ºC no layering phenomenon
Solid content	6.20.2%
Proportion	0.80±0.05
Acid value	19.2 ±1.0 mgKOH/g
Halogen content	No

 Reliability performance

Project	Technical requirements	Test result
Water extract resistivity	JIS Z3197-86 JIS Z3283-86	By：5.0×104 ohm·cm
Bronze corrosion	IPC-TM-650 2.3.32	Pass
AgCrO4	IPC-TM-650 2.3.33	Pass
Halogen content	JIS Z3197-86 JIS Z3283-86	Pass
Boiling point	81-120℃
Buring Point	>250℃(300-400℃)
PH	6
Color	Colorless/light yellow
Gravity	0.82

Surface insulation resistance

Standard test	Conditions	Standard	Test result
IPC-TM-650 2.6.3.3	40ºC, 95% RH, 96h	> 1.0×1011 Ohms	4.9×1011

SHENZHEN BBIEN TECHNOLOGY LIMITED'S lead free Liquid Flux is a water-washable, no-clean formula designed for Lead-Free soldering of high quality electronic printed circuit boards (PCBs), including through-hole, mixed technology, and surface mount assembles. Use of BBIEN’s lead free liquid flux eliminates the need for post cleaning operation. If post cleaning is required, this liquid flux can be cleaned using water. Flux may be applied using foam or spray applications as supplied.
FLUX APPLICATION:

Project	Suggest parameters
Flux coated(Spray method)	750-1500g/in² Solid content
Surface of board preheated temperature	110-160°C
Under the board the preheated temperature	About 35°C higher than surface
Board heating rate	Max 2°C/s
Tilt angle of conveyor belt	5-7°, in general 5.7-6°
Speed of conveyor belt	1.0-1.8 m/min，in general 1.2 m/min
Wave crest of time	1.5-3.5s，in general 2.0-2.5s
Tin stove temperature	250-350°C
Note：The above parameters for reference only，don't guarantee to obtain the best welding effect.As the different conditions of the equipment, components, PCB aspects of user,user had better use experimental design method to obtain the iptimum parameters.

Result of Used for different materials products

Material	Compatibility
304 stainless steel	Good
316 stainless steel	Good
ABS plastic	Not Compatible
Aluminium	Excellent
Brass	Excellent
Bronze	Excellent
Carbon Graphite	Excellent
Carbon Steel	Excellent
Copper	Excellent
Epoxy	Good
Fluorocarbon	Good
LDPE	Good
Natural Rubber	Not Compatible
Neoprene	Not Compatible
Nylon	Excellent
Polycarbonate	Not Compatible
Polypropylene	Good
Polyurethane	Not Compatible
PVC	Not Compatible
Silicone	Not Compatible

Lead free liquid flux is used for wave soldering welding,wave PCB.
Can be match with tin solder bar,spatter to PCB during wave soldering process.

The flux belongs to wave soldering using flux. Special design to meet the wettability for wave soldering.
Bright spot welding. Soldering flux in the appropriate internal activity solid content and its mechanism ensure the little residue after welding circuit,and board surface drying, cleaning. In un-specificness conditions,it exempt cleaning process,then save the operating costs of manufacture.It has with excellent welding performance.For wave soldering can reduce bridge or other defects.

shenzhen bbien technology limited;s flux Packing:20L/drum

Storage and Shelf Life:
BBIEN lead free solder flux is flammable. Store away from sources of ignition. Shelf life is 2 years from date of manufacture
when handled properly and held at 10-25°C (50-77°F).

Health & Safety:
This product, during handling or use, may be hazardous to health or the environment. Read the Material Safety
Data Sheet and warning label before using this product.
