BBIEN supply Low temperature Bi/bismuth series powder of Sn42Bi58,Sn64Bi35Ag1 and Sn64.7Bi35Ag0.3 Sn-Bi powder,Sn-Bi-Ag solder powder.

1.The welding powder is ball shaped,the dark part is a tin rich area and the light part is a lead rich area.The pictures show the good sphericity, homogenous alloy composition and smooth surface of the product.

2.Particle size classification and final typing technology enables stable particle size of the product provided to customers.

3. Low oxygen content
Oxygen content is strictly controlled during production and packing of allalloy welding powder.Leco oxygen determinator is adopted to determine the surface oxygen content and chemical assay is adopted to determine the total oxygen content.

4.Advanced powder classification and collection technology enables Type 2-Type 3 alloy welding powder free of powder smaller than 20um.

（1）Product specifications: we can provide conforms to the J - STD - 005 standard specifications welding powder products; Typical particle size distribution table as follows, if you have any special request, please contact with us (another schedule):

Specification	Particle size classification	Particle size			Reference Standard
2.5#	-230/+500目 -230/+500mesh	>63μm	25-63μm	<25μm	J-STD-005
		max1wt%	min85wt%	max5.0wt%
2.3#	-230/+400目 -230/+400mesh	>63μm	38-63μm	<38μm
		max1wt%	min85wt%	max5.0wt%
3#	-325/+500目 -325/+500mesh	>45μm	25-45μm	<25μm
		max1wt%	min85wt%	max10.0wt%
4#	-400/+500目 -400/+500mesh	>38μm	20-38μm	<20μm
		max1wt%	min85wt%	max10.0wt%

（2）Product oxygen content: (appendix):

specification	particle size	oxygen content(ppm)
2.5#	25-63μm	<80
2.3#	38-63μm	<70
3#	25-45μm	<90
4#	20-38μm	<120

Raw material review,synchronous sampling,periodic submission of samples to authorities sampling inspetion, advanced chemical and particle size testingapparatuses,timely follow-up and feedback of product information constitute our complete quality supervision system that guarantees the quality of our products.

BBIEN  technology atomization technology production of spherical alloy solder powder, under accurate monitoring by the computer,It is  carrying out the high quality standard of the alloy solder powder,It can satisfy with the high quality demand of the solder paste . We can also according to customer requirements produce all kinds of special performance products.

BBIEN's common solder poder profile:

SMT solder powder	melting point °C	Type no.	Application
Sn63Pb37	183	Type2-7	PCB
Sn96.5Ag3.5	222	Type2-5	SMT,cellphone component
Sn96.5Ag3.0Cu0.5	217	Type2-7	SMD、SMT LED、PCB
Sn99.0Ag0.3Cu0.7
Sn64Bi35Ag1	179	Type2-7	SMT,PCB
Sn64.7Bi35Ag0.3	179	Type2-6	LED
Sn42Bi57.6g0.4	179	Type2-4	LED
Sn62Pb36Ag2	183	Type2-7	SMT,PCB
Sn42Bi58	138	Type2-4	LED

Packaging:All BBIEN powder is packaged in 5kg metallized mylar bags under inert gas. FIVE bags are packed in sealed polyethylene containers to prevent damage. Alternative packaging is available to satisfy customer requirements.

Facility Capacity:BBIEN’s powder facility is capable of producing 2000~100,000 kg of finished solder powder per Month.

Certificate of Analysis:All BBIEN powder is delivered with a detailed CofA including
chemical analysis and image analysis size distribution. Coullter particle distribution available upon request
