Sn50Pb50 Pb flux core tin lead solder wire
main Pb solder wire
Sn50Pb50 Pb flux core tin lead solder wire
Sn50Pb50RA water-soluble core wire is a very low halide（<1000ppm）, water-soluble flux cored solder.the flux core type can be divided into 1.5%,2.0%.3.0% Its post-soldering residue is water-soluble and can be easily cleaned with DI water. Our water-soluble core wire is recommended for use in any hand soldering application where high flux activity is desired.
Datasheet for Sn50Pb50 core wire solder
main content Impurity content%
Standard Sn Pb Sb Ag Cu Fe Zn Bi Al As Ni Cd
50±2 bal ≤0.10% ≤0.02% 0.1% ≤0.02% ≤0.001% ≤0.10% ≤0.001% ≤0.03% ≤0.01% <0.01%
Testing result 51 bal 0.032 0.0002 0.0057 0.002 0.0015 0.006 0.0024 0.0021 0.0032 0.0001
Flux core contents


Feature:

. Fast welding speed, superb wettibility,terrific expandability.
 The tin-lead wire added the activated core 2%,featuring fast melting speed, superb wettibility,terrific expandability.Thereby it can offer distinguished soldering performance.

.Wonderful electrical conductivity, no core breakage and no splash.

.High temperature anti-oxygen

.Satisfactory soldering joint and favorable fluidity.

Solder joints are filled, and firm. Both RA and RMA are made in complicance with IPC J-STD-006 and JIS Z3283 class AA standards. All these solder flux can be dissolved in solvent, featuring a little smoke and very few splatters.

.Flux content ranges from 1.5% to 3.5%, while the wire diameter can be opatinal avove 0.35mm(0.4mm,0.5mm,0.8mm,1.0mm…)
